Description
| Category | Specification |
|---|---|
| Standards & Protocols | IEEE 802.3i / 802.3u / 802.3ab / 802.3x / 802.1p |
| Interface | 8 × 10/100/1000 Mbps Ports, Auto-Negotiation, Auto-MDI/MDIX |
| Fan Quantity | Fanless |
| External Power Supply | 9VDC / 0.6A |
| LED Indicators | System Power, Link/Act per port |
| Buffer Size | 1.5 Mb |
| Dimensions (W×D×H) | 6.2 × 4.0 × 1.0 in (158 × 101 × 25 mm) |
| Max Power Consumption | 3.3 W |
| Max Heat Dissipation | 11.3 BTU/h |
| Packet Forwarding Rate | 11.9 Mpps |
| MAC Address Table | 4K |
| Packet Buffer Memory | 1.5 Mb |
| Jumbo Frame | 16 KB |
| Advanced Features | Green Technology (saves up to 82%), 802.3X Flow Control, 802.1p/DSCP QoS, IGMP Snooping |
| Transmission Method | Store-and-Forward |
| Certification | CE, FCC, RoHS |
| Package Content | 8-Port Desktop Switch, Power Adapter, Installation Guide |
| Operating Temperature | 0°C ~ 40°C (32°F ~ 104°F) |
| Storage Temperature | -40°C ~ 70°C (-40°F ~ 158°F) |
| Operating Humidity | 10% ~ 90%, non-condensing |
| Storage Humidity | 5% ~ 90% |
