Description
| Category | Specification |
|---|---|
| Model | CS-DP2C |
| Installation Parameters | Supported Hole Diameter: 16.5 – 50 mm (0.65 – 1.97 in)Supported Door Diameter: 35 – 105 mm (1.38 – 4.13 in) |
| Camera Parameters | Sensor: 1/3" Progressive Scan CMOSLens: 2.0 mm @ F2.2, 155° (Diagonal)Day/Night: ICR infrared filterIR Distance: Max. 5 mMax. Resolution: 1080p / 2MPFrame Rate: 15 fps |
| PIR Detection | Angle: 110°Distance: Max. 6 m (20 ft)Sensitivity: Adjustable |
| Interface | Storage: MicroSD card slot (up to 512 GB)Audio Input: Built-in high-sensitivity micAudio Output: Built-in high-power speakerButtons: Doorbell, Power, Screen wake-up |
| Network | Face Detection: Not SupportedIntelligence Alarm: PIR motion detectionProtocol: EZVIZ Cloud ProprietaryVideo Intercom: Local & remoteSecurity: Cloud video & image encryption |
| Wireless | Wi-Fi: IEEE802.11b/g/nFrequency: 2.4 – 2.4835 GHzBandwidth: 20 MHzSecurity: WEP 64/128-bit, WPA/WPA2, WPA-PSK/WPA2-PSK, WPSTransmission: 11b: 11 Mbps, 11g: 54 Mbps, 11n: 150 Mbps |
| General | Screen: 4.3-inch colorColor Options: Silver / GoldenOperating Temp: -10°C ~ 45°C (14°F ~ 113°F)Humidity: ≤ 95% (non-condensing)Power Supply: DC 5V (±10%)Power Consumption: Max. 2.2 W |
| Dimensions & Weight | Screen & Base: 115.5 × 85.5 × 24.5 mm (4.55 × 3.37 × 0.96 in)Peephole Doorbell: 71 × 71 × 48.3 mm (2.80 × 2.80 × 1.90 in)Weight: 302 g (10.65 oz) |
