Description
| Category | Specification |
|---|---|
| Image Sensor | 2 MP CMOS |
| Signal System | PAL / NTSC |
| Max. Resolution | 1920 (H) × 1080 (V) |
| Min. Illumination | 0.02 Lux @ (F1.2, AGC ON); 0 Lux with IR |
| Shutter Time | PAL: 1/25 s to 1/50,000 s NTSC: 1/30 s to 1/50,000 s |
| Day & Night | IR Cut Filter |
| Angle Adjustment | Pan: 0°–360° Tilt: 0°–75° Rotation: 0°–360° |
| Lens | Type: 2.8 mm, 3.6 mm Fixed Lens Focal Length & FOV: - 2.8 mm: H 96.5°, V 48.9°, D 120.5° - 3.6 mm: H 76.9°, V 40.6°, D 92.0° Lens Mount: M12 |
| Illuminator | IR Range: Up to 20 m |
| Image | Frame Rate: - TVI: 1080p @ 25/30 fps - AHD: 1080p @ 25/30 fps - CVI: 1080p @ 25/30 fps - CVBS: PAL/NTSC WDR: Digital WDR Mode: Auto / Color / B&W White Balance: Auto Enhancement: DWDR, BLC, Global Noise Reduction: 2D DNR Image Settings: Brightness, Mirror, Smart IR, Sharpness, AGC |
| Interface | Video Output: Switchable TVI/AHD/CVI/CVBS |
| General | Language: English Operating Conditions: -40°C ~ 60°C (-40°F ~ 140°F), ≤90% RH (non-condensing) Material: Plastic Communication: HIKVISION-C |
| Dimensions & Weight | Φ 84.6 × 78.9 mm (Φ 3.33" × 3.11") Weight: Approx. 195 g (0.43 lb) |
| Power | 12 VDC ± 25%, Max. 3.3 W |
